1” A100 Aluminum
Up to 41 GPM
Elastomer Available in: Geolast®, Santoprene®, PTFE, Viton, Nitrile
Liquid Connections Available in: NPT, BSPT
Max Solids: 1/4 Inch (6.4mm)
Max Suction Lift (Dry): 17ft-H20 (5.2m)
Max Suction Lift (Wet): 30ft-H20 (9.1m)
Air Inlet: 1/2 Inch FNPT
![]()
1” A100 Aluminum
| Part No. | Fluid End | Air End | Diaphragms | Valve/Ball | Valve Seats | O-Rings | Connection Type | Fluid Porting |
|---|---|---|---|---|---|---|---|---|
| A100-BAA-GGPN-B30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | BSPBSP Connection | Suction Center Front/Discharge Center RearSuction Center Front/Discharge Center Rear |
| A100-BAA-GTPN-B30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | PTFEThermoplastic material that is inert to most chemicals. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | BSPBSP Connection | Suction Center Front/Discharge Center RearSuction Center Front/Discharge Center Rear |
| A100-BAA-NNPN-B30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | BSPBSP Connection | Suction Center Front/Discharge Center RearSuction Center Front/Discharge Center Rear |
| A100-BAA-SSPE-B30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | BSPBSP Connection | Suction Center Front/Discharge Center RearSuction Center Front/Discharge Center Rear |
| A100-BAA-TTYT-B30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | NylonA non-metallic material, suitable for most solvents and oils. | PTFEThermoplastic material that is inert to most chemicals. | BSPBSP Connection | Suction Center Front/Discharge Center RearSuction Center Front/Discharge Center Rear |
| A100-BAA-VVYV-B30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NylonA non-metallic material, suitable for most solvents and oils. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | BSPBSP Connection | Suction Center Front/Discharge Center RearSuction Center Front/Discharge Center Rear |
| A100-NAA-GGPN-B30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | NPT | Suction Center Front/Discharge Center RearSuction Center Front/Discharge Center Rear |
| A100-NAA-GTPN-B30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | PTFEThermoplastic material that is inert to most chemicals. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | NPT | Suction Center Front/Discharge Center RearSuction Center Front/Discharge Center Rear |
| A100-NAA-NNPN-B30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | NPT | Suction Center Front/Discharge Center RearSuction Center Front/Discharge Center Rear |
| A100-NAA-SSPE-B30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | NPT | Suction Center Front/Discharge Center RearSuction Center Front/Discharge Center Rear |
| A100-NAA-TTYT-B30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | NylonA non-metallic material, suitable for most solvents and oils. | PTFEThermoplastic material that is inert to most chemicals. | NPT | Suction Center Front/Discharge Center RearSuction Center Front/Discharge Center Rear |
| A100-NAA-VVYV-B30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NylonA non-metallic material, suitable for most solvents and oils. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NPT | Suction Center Front/Discharge Center Rear |
1" A100 Stainless Steel
Up to 41 GPM
Elastomer Available in: Geolast®, Santoprene®, PTFE, Viton
Liquid Connections Available in: NPT, BSPT
Max Solids: 1/4 Inch (6.4mm)
Max Suction Lift (Dry): 17ft-H20 (5.2m)
Max Suction Lift (Wet): 30ft-H20 (9.1m)
Air Inlet: 1/2 Inch FNPT
![]()
1" A100 Stainless Steel
| Part No. | Fluid End | Air End | Diaphragms | Valve/Ball | Valve Seats | O-Rings | Connection Type | Fluid Porting |
|---|---|---|---|---|---|---|---|---|
| A100-BA3-GG3N-B70 | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | AluminumAluminum | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | BSPBSP Connection | Suction Center Front/Discharge Center RearSuction Center Front/Discharge Center Rear |
| A100-BA3-VV3V-B70 | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | AluminumAluminum | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | BSPBSP Connection | Suction Center Front/Discharge Center RearSuction Center Front/Discharge Center Rear |
| A100-NA3-GG3N-B70 | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | AluminumAluminum | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | NPT | Suction Center Front/Discharge Center RearSuction Center Front/Discharge Center Rear |
| A100-NA3-SS3E-B70 | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | AluminumAluminum | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | NPT | Suction Center Front/Discharge Center RearSuction Center Front/Discharge Center Rear |
| A100-NA3-TT3T-B70 | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | AluminumAluminum | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | PTFEThermoplastic material that is inert to most chemicals. | NPT | Suction Center Front/Discharge Center RearSuction Center Front/Discharge Center Rear |
| A100-NA3-VV3V-B70 | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | AluminumAluminum | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NPT | Suction Center Front/Discharge Center Rear |
1” A100 Polypropylene
Up to 41 GPM
Elastomer Available in: Geolast®, Santoprene®, PTFE, Viton
Liquid Connections Available in: ANSI/DIN Flange, FNPT, FBSPT
Max Solids: 1/4 Inch (6.4mm)
Max Suction Lift (Dry): 15ft-H20 (4.5m)
Max Suction Lift (Wet): 26ft-H20 (7.9m)
Air Inlet: ¼ Inch FNPT
![]()
1” A100 Polypropylene
| Part No. | Fluid End | Air End | Diaphragms | Valve/Ball | Valve Seats | O-Rings | Connection Type | Fluid Porting |
|---|---|---|---|---|---|---|---|---|
| A100-CPP-GGPN-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | NPT & ANSI / DIN FlangeNPT & ANSI / DIN Flange Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A100-CPP-SSPE-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | NPT & ANSI / DIN FlangeNPT & ANSI / DIN Flange Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A100-CPP-TTPT-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | PTFEThermoplastic material that is inert to most chemicals. | NPT & ANSI / DIN FlangeNPT & ANSI / DIN Flange Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A100-CPP-VVPV-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NPT & ANSI / DIN FlangeNPT & ANSI / DIN Flange Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A100-EPP-GGPN-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | BSP & ANSI / DIN FlangeBSP & ANSI / DIN Flange Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A100-EPP-SSPE-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | BSP & ANSI / DIN FlangeBSP & ANSI / DIN Flange Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A100-EPP-TTPT-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | PTFEThermoplastic material that is inert to most chemicals. | BSP & ANSI / DIN FlangeBSP & ANSI / DIN Flange Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A100-EPP-VVPV-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | BSP & ANSI / DIN FlangeBSP & ANSI / DIN Flange Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A100-FPP-GGPN-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | ANSI / DIN FlangeANSI / DIN Flange Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A100-FPP-SSPE-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | ANSI / DIN FlangeANSI / DIN Flange Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A100-FPP-TTPT-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | PTFEThermoplastic material that is inert to most chemicals. | ANSI / DIN FlangeANSI / DIN Flange Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A100-FPP-VVPV-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | ANSI / DIN FlangeANSI / DIN Flange Connection | Suction Right/Discharge Right |
1” C100 Polypropylene Clamped Style Pump
Up to 41 GPM
Elastomer Available in: Geolast®, Santoprene®, PTFE, Viton
Liquid Connections Available in:ANSI/DIN Flange, FNPT, FBSPT
Max Solids: 1/4 Inch (6.4mm)
Max Suction Lift (Dry): 15ft-H20 (4.5m)
Max Suction Lift (Wet): 26ft-H20 (7.9m)
Air Inlet: ¼ Inch FNPT
![]()
1” C100 Polypropylene Clamped Style Pump
| Part No. | Fluid End | Air End | Diaphragms | Valve/Ball | Valve Seats | O-Rings | Connection Type | Fluid Porting |
|---|---|---|---|---|---|---|---|---|
| C100-BPP-GGPN-G70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | BSPBSP Connection | Suction Center Rear/Discharge Center RearSuction Center Rear/Discharge Center Rear |
| C100-BPP-SSPE-G70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | BSPBSP Connection | Suction Center Rear/Discharge Center RearSuction Center Rear/Discharge Center Rear |
| C100-BPP-TTPT-G70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | PTFEThermoplastic material that is inert to most chemicals. | BSPBSP Connection | Suction Center Rear/Discharge Center RearSuction Center Rear/Discharge Center Rear |
| C100-BPP-VVPV-G70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | BSPBSP Connection | Suction Center Rear/Discharge Center RearSuction Center Rear/Discharge Center Rear |
| C100-NPP-GGPN-G70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | NPT | Suction Center Rear/Discharge Center RearSuction Center Rear/Discharge Center Rear |
| C100-NPP-SSPE-G70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | NPT | Suction Center Rear/Discharge Center RearSuction Center Rear/Discharge Center Rear |
| C100-NPP-TTPT-G70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | PTFEThermoplastic material that is inert to most chemicals. | NPT | Suction Center Rear/Discharge Center RearSuction Center Rear/Discharge Center Rear |
| C100-NPP-VVPV-G70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NPT | Suction Center Rear/Discharge Center Rear |
1” A100 PVDF
Up to 41 GPM
Elastomer Available in: Santoprene®, PTFE, Viton
Liquid Connections Available in: ANSI/DIN Flange
Max Solids: 1/4 Inch (6.4mm)
Max Suction Lift (Dry): 15ft-H20 (4.5m)
Max Suction Lift (Wet): 26ft-H20 (7.9m)
Air Inlet: ¼ Inch FNPT
1” A100 PVDF
| Part No. | Fluid End | Air End | Diaphragms | Valve/Ball | Valve Seats | O-Rings | Connection Type | Fluid Porting |
|---|---|---|---|---|---|---|---|---|
| A100-CPK-SSKE-S70 | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | NPT & ANSI / DIN FlangeNPT & ANSI / DIN Flange Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A100-CPK-TTKT-S70 | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | PTFEThermoplastic material that is inert to most chemicals. | NPT & ANSI / DIN FlangeNPT & ANSI / DIN Flange Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A100-CPK-VVKV-S70 | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NPT & ANSI / DIN FlangeNPT & ANSI / DIN Flange Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A100-EPK-SSKE-S70 | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | BSP & ANSI / DIN FlangeBSP & ANSI / DIN Flange Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A100-EPK-TTKT-S70 | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | PTFEThermoplastic material that is inert to most chemicals. | BSP & ANSI / DIN FlangeBSP & ANSI / DIN Flange Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A100-EPK-TTKT-S70 | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | BSP & ANSI / DIN FlangeBSP & ANSI / DIN Flange Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A100-FPK-SSKE-S70 | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | ANSI / DIN FlangeANSI / DIN Flange Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A100-FPK-TTKT-S70 | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. |
