1/2” A050 Aluminum
Up to 17 GPM
Elastomer Available in: Geolast®, Santoprene®, PTFE, Viton
Liquid Connections Available in: FNPT, FBSPT
Max Solids: 1/8 Inch (3.2mm)
Max Suction Lift (Dry): 15ft-H20 (4.5m)
Max Suction Lift (Wet): 31ft-H20 (9.4m)
Air Inlet: ¼ Inch FNPT
![]()
1/2” A050 Aluminum
| Part No. | Fluid End | Air End | Diaphragms | Valve/Ball | Valve Seats | O-Rings | Connection Type | Fluid Porting |
|---|---|---|---|---|---|---|---|---|
| A050-BAA-GGPN-S30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | BSPBSP Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-BAA-GTPN-S30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | PTFEThermoplastic material that is inert to most chemicals. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | BSPBSP Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-BAA-SSPE-S30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | BSPBSP Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-BAA-TTYT-S30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | NylonA non-metallic material, suitable for most solvents and oils. | PTFEThermoplastic material that is inert to most chemicals. | BSPBSP Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-BAA-VVYV-S30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NylonA non-metallic material, suitable for most solvents and oils. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | BSPBSP Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-NAA-GGPN-S30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | NPT | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-NAA-GTPN-S30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | PTFEThermoplastic material that is inert to most chemicals. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | NPT | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-NAA-SSAE-S30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | NPT | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-NAA-SSPE-S30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | NPT | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-NAA-TTYT-S30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | NylonA non-metallic material, suitable for most solvents and oils. | PTFEThermoplastic material that is inert to most chemicals. | NPT | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-NAA-VVYV-S30 | AluminumGeneral Purpose metal, suitable for water, oils, most solvents, most paints. | AluminumAluminum | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NylonA non-metallic material, suitable for most solvents and oils. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NPT | Suction Right/Discharge Right |
1/2” A050 Stainless Steel
Up to 17 GPM
Elastomer Available in: Geolast®, Santoprene®, PTFE, Viton
Liquid Connections Available in: FNPT, FBSPT
Max Solids: 1/8 Inch (3.2mm)
Max Suction Lift (Dry): 15ft-H20 (4.5m)
Max Suction Lift (Wet): 31ft-H20 (9.4m)
Air Inlet: ¼ Inch FNPT
![]()
1/2” A050 Stainless Steel
| Part No. | Fluid End | Air End | Diaphragms | Valve/Ball | Valve Seats | O-Rings | Connection Type | Fluid Porting |
|---|---|---|---|---|---|---|---|---|
| A050-BA3-GG3N-S70 | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | AluminumAluminum | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | BSPBSP Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-BA3-GT3N-S70 | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | AluminumAluminum | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | PTFEThermoplastic material that is inert to most chemicals. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | BSPBSP Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-BA3-SS3E-S70 | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | AluminumAluminum | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | BSPBSP Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-BA3-TT3T-S70 | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | AluminumAluminum | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | PTFEThermoplastic material that is inert to most chemicals. | BSPBSP Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-BA3-VV3V-S70 | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | AluminumAluminum | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | BSPBSP Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-BP3-GG3N-S70 | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | BSPBSP Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-BP3-SS3E-S70 | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | BSPBSP Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-BP3-TT3T-S70 | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | PTFEThermoplastic material that is inert to most chemicals. | BSPBSP Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-NA3-GG3N-S70 | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | AluminumAluminum | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | NPT | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-NA3-GT3N-S70 | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | AluminumAluminum | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | PTFEThermoplastic material that is inert to most chemicals. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | NPT | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-NA3-SS3E-S70 | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | AluminumAluminum | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | NPT | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-NA3-TT3T-S70 | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | AluminumAluminum | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | PTFEThermoplastic material that is inert to most chemicals. | NPT | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-NA3-VV3V-S70 | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | AluminumAluminum | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NPT | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-NP3-GG3N-S70 | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | NPT | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-NP3-TT3T-S70 | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | PTFEThermoplastic material that is inert to most chemicals. | NPT | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-NP3-VV3V-S70 | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NPT | Suction Right/Discharge Right |
1/2” A050 Polypropylene
Up to 17 GPM
Elastomer Available in: Geolast®, Santoprene®, PTFE, Viton
Liquid Connections Available in: FNPT, FBSPT
Max Solids: 1/8 Inch (3.2mm)
Max Suction Lift (Dry): 15ft-H20 (4.5m)
Max Suction Lift (Wet): 26ft-H20 (7.9m)
Air Inlet: ¼ Inch FNPT
![]()
1/2” A050 Polypropylene
| Part No. | Fluid End | Air End | Diaphragms | Valve/Ball | Valve Seats | O-Rings | Connection Type | Fluid Porting |
|---|---|---|---|---|---|---|---|---|
| A050-SPP-GGPN-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge RightSuction Right/Discharge Right |
| A050-SPP-SSPE-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Right (NPT/BSP Only)Suction Right/Discharge Right (NPT/BSP Only) |
| A050-SPP-SSPE-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | NPT (BSP)NPT(BSP) Connection | Suction Left/ Discharge Left (NPT/BSP Only)Suction Left/ Discharge Left (NPT/BSP Only) |
| A050-SPP-TTPT-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | PTFEThermoplastic material that is inert to most chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Right (NPT/BSP Only)Suction Right/Discharge Right (NPT/BSP Only) |
| A050-SPP-VVPV-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Right (NPT/BSP Only) |
1/2” C050 Clamped Polypropylene
Up to 17 GPM
Elastomer Available in: Geolast®, Santoprene®, PTFE, Viton
Liquid Connections Available in: FNPT, FBSPT
Max Solids: 1/8 Inch (3.2mm)
Max Suction Lift (Dry): 15ft-H20 (4.5m)
Max Suction Lift (Wet): 26ft-H20 (7.9m)
Air Inlet: ¼ Inch FNPT
![]()
1/2” C050 Clamped Polypropylene
| Part No. | Fluid End | Air End | Diaphragms | Valve/Ball | Valve Seats | O-Rings | Connection Type | Fluid Porting |
|---|---|---|---|---|---|---|---|---|
| C050-SPK-TTKT-G70 | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | PTFEThermoplastic material that is inert to most chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Center Rear/Discharge Center RearSuction Center Rear/Discharge Center Rear |
| C050-SPP-GGPN-G70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | NPT (BSP)NPT(BSP) Connection | Suction Center Rear/Discharge Center RearSuction Center Rear/Discharge Center Rear |
| C050-SPP-SSPE-G70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | NPT (BSP)NPT(BSP) Connection | Suction Center Rear/Discharge Center RearSuction Center Rear/Discharge Center Rear |
| C050-SPP-TTPT-G70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | PTFEThermoplastic material that is inert to most chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Center Rear/Discharge Center RearSuction Center Rear/Discharge Center Rear |
| C050-SPP-VVPV-G70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Center Rear/Discharge Center Rear |
1/2” A050 PVDF
Up to 17 GPM
Elastomer Available in: Santoprene®, PTFE, Viton
Liquid Connections Available in: FNPT, FBSPT
Max Solids: 1/8 Inch (3.2mm)
Max Suction Lift (Dry): 15ft-H20 (4.5m)
Max Suction Lift (Wet): 26ft-H20 (7.9m)
Air Inlet: ¼ Inch FNPT
![]()
1/2” A050 PVDF
| Part No. | Fluid End | Air End | Diaphragms | Valve/Ball | Valve Seats | O-Rings | Connection Type | Fluid Porting |
|---|---|---|---|---|---|---|---|---|
| A050-SPK-SSKE-S70 | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Right (NPT/BSP Only)Suction Right/Discharge Right (NPT/BSP Only) |
| A050-SPK-TTKT-S70 | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | PTFEThermoplastic material that is inert to most chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Right (NPT/BSP Only)Suction Right/Discharge Right (NPT/BSP Only) |
| A050-SPK-VVKV-S70 | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Right (NPT/BSP Only) |
1/2” C050 Clamped PVDF
Up to 17 GPM
Elastomer Available in: Santoprene®, PTFE, Viton
Liquid Connections Available in: FNPT, FBSPT
Max Solids: 1/8 Inch (3.2mm)
Max Suction Lift (Dry): 15ft-H20 (4.5m)
Max Suction Lift (Wet): 26ft-H20 (7.9m)
Air Inlet: ¼ Inch FNPT
![]()
1/2” C050 Clamped PVDF
| Part No. | Fluid End | Air End | Diaphragms | Valve/Ball | Valve Seats | O-Rings | Connection Type | Fluid Porting |
|---|---|---|---|---|---|---|---|---|
| C050-SPK-SSKE-G70 | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | NPT (BSP)NPT(BSP) Connection | Suction Center Rear/Discharge Center RearSuction Center Rear/Discharge Center Rear |
| C050-SPK-VVKV-G70 | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Bottom/Discharge Center Rear |
1/2” A050 Conductive Nylon
Up to 17 GPM
Elastomer Available in: Geolast®, PTFE, Viton
Liquid Connections Available in: FNPT, FBSPT
Max Solids: 1/8 Inch (3.2mm)
Max Suction Lift (Dry): 15ft-H20 (4.5m)
Max Suction Lift (Wet): 26ft-H20 (7.9m)
Air Inlet: ¼ Inch FNPT
1/2” A050 Conductive Nylon
| Part No. | Fluid End | Air End | Diaphragms | Valve/Ball | Valve Seats | O-Rings | Connection Type | Fluid Porting |
|---|---|---|---|---|---|---|---|---|
| A050-SPY-GN3N-SF0 | Conductive Nylon Stainless Steel filled Nylon, suitable for most solvents and alcohols. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Right (NPT/BSP Only)Suction Right/Discharge Right (NPT/BSP Only) |
| A050-SPY-TT3T-SF0 | Conductive Nylon Stainless Steel filled Nylon, suitable for most solvents and alcohols. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | PTFEThermoplastic material that is inert to most chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Right (NPT/BSP Only)Suction Right/Discharge Right (NPT/BSP Only) |
| A050-SPY-VV3V-SF0 |
