3/8” C038 Polypropylene
Up to 9 GPM
Elastomer Available in: Geolast®, Santoprene®, PTFE
Liquid Connections Available in: FNPT, FBSPT
Max Solids: 1/16 Inch (1.6mm)
Max Suction Lift (Dry): 15ft-H20 (4.5m)
Max Suction Lift (Wet): 26ft-H20 (7.9m)
Air Inlet: ¼ Inch FNPT
![]()
3/8” C038 Polypropylene
| Part No. | Fluid End | Air End | Diaphragms | Valve/Ball | Valve Seats | O-Rings | Connection Type | Fluid Porting |
|---|---|---|---|---|---|---|---|---|
| C038-SQP-GGPN-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Right (NPT/BSP Only)Suction Right/Discharge Right (NPT/BSP Only) |
| C038-SQP-SSPE-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Right (NPT/BSP Only)Suction Right/Discharge Right (NPT/BSP Only) |
| C038-SQP-TTPT-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | PTFEThermoplastic material that is inert to most chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Right (NPT/BSP Only)Suction Right/Discharge Right (NPT/BSP Only) |
| C038-SQP-TVPV-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Right (NPT/BSP Only) |
3/8” C038 PVDF
Up to 9 GPM
Elastomer Available in: Santoprene®, PTFE
Liquid Connections Available in: FNPT, FBSPT
Max Solids: 1/16 Inch (1.6mm)
Max Suction Lift (Dry): 15ft-H20 (4.5m)
Max Suction Lift (Wet): 26ft-H20 (7.9m)
Air Inlet: ¼ Inch FNPT
![]()
3/8” C038 PVDF
| Part No. | Fluid End | Air End | Diaphragms | Valve/Ball | Valve Seats | O-Rings | Connection Type | Fluid Porting |
|---|---|---|---|---|---|---|---|---|
| C038-SQK-SSKE-S70 | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Right (NPT/BSP Only)Suction Right/Discharge Right (NPT/BSP Only) |
| C038-SQK-TTKT-S70 | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | PTFEThermoplastic material that is inert to most chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Right (NPT/BSP Only)Suction Right/Discharge Right (NPT/BSP Only) |
| C038-SQK-TVKV-S70 | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Right (NPT/BSP Only) |
3/8” C038 Conductive Nylon
Up to 9 GPM
Elastomer Available in: Geolast®, PTFE
Liquid Connections Available in: FNPT, FBSPT
Max Solids: 1/16 Inch (1.6mm)
Max Suction Lift (Dry): 15ft-H20 (4.5m)
Max Suction Lift (Wet): 26ft-H20 (7.9m)
Air Inlet: ¼ Inch FNPT
![]()
3/8” C038 Conductive Nylon
| Part No. | Fluid End | Air End | Diaphragms | Valve/Ball | Valve Seats | O-Rings | Connection Type | Fluid Porting |
|---|---|---|---|---|---|---|---|---|
| C038-SQY-GG3N-SF0 | Conductive Nylon Stainless Steel filled Nylon, suitable for most solvents and alcohols. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Left (NPT/BSP Only)Suction Right/Discharge Left (NPT/BSP Only) |
| C038-SQY-TT3T-SF0 | Conductive Nylon Stainless Steel filled Nylon, suitable for most solvents and alcohols. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | PTFEThermoplastic material that is inert to most chemicals. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | PTFEThermoplastic material that is inert to most chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Bottom/Discharge RightSuction Bottom/Discharge Right |
| C038-SQY-TV3V-SF0 | Conductive Nylon Stainless Steel filled Nylon, suitable for most solvents and alcohols. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Bottom/Discharge Right |
3/8" C038 Drum Ready Pump
Up to 9 GPM
Elastomer Available in: Geolast®, Santoprene®, PTFE
Liquid Connections Available in: FNPT, FBSPT
Max Solids: 1/4 Inch (6.4mm)
Max Suction Lift (Dry): 15ft-H20 (4.5m)
Max Suction Lift (Wet): 26ft-H20 (7.9m)
Air Inlet: ¼ Inch FNPT
![]()
3/8" C038 Drum Ready Pump
| Part No. | Fluid End | Air End | Diaphragms | Valve/Ball | Valve Seats | O-Rings | Connection Type | Fluid Porting |
|---|---|---|---|---|---|---|---|---|
| C038-SQK-TTKT-N70 | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | PTFE Ball | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | PTFEThermoplastic material that is inert to most chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Bottom/Discharge RightSuction Bottom/Discharge Right |
| C038-SQP-TTPT-N70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | PTFE Ball | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | PTFEThermoplastic material that is inert to most chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Bottom/Discharge RightSuction Bottom/Discharge Right |
| C038-SQY-TT3T-NF0 | Conductive Nylon Stainless Steel filled Nylon, suitable for most solvents and alcohols. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | PTFE Ball | Stainless SteelCorrosion Resistant Steel, suitable for nitric acid, chlorinated solvents, caustics and marine applications. | PTFEThermoplastic material that is inert to most chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Bottom/Discharge RightSuction Bottom/Discharge Right |
| S038-SQK-SEKE-N70 | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | EPDM Max-Pass®Max-Pass® valve made from EPDM rubber. | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | NPT (BSP)NPT(BSP) Connection | Suction Bottom/Discharge RightSuction Bottom/Discharge Right |
| S038-SQK-TVKV-N70 | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | Viton® Max-Pass®Max-Pass® valve made from Viton® rubber. | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Bottom/Discharge RightSuction Bottom/Discharge Right |
| S038-SQP-GNPN-N70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Nitrile Max-Pass®Max-Pass® valve made from Nitrile rubber. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | NPT (BSP)NPT(BSP) Connection | Suction Bottom/Discharge RightSuction Bottom/Discharge Right |
| S038-SQP-SEPE-N70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | EPDM Max-Pass®Max-Pass® valve made from EPDM rubber. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | NPT (BSP)NPT(BSP) Connection | Suction Bottom/Discharge RightSuction Bottom/Discharge Right |
| S038-SQP-TVPV-N70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | Viton® Max-Pass®Max-Pass® valve made from Viton® rubber. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Bottom/Discharge RightSuction Bottom/Discharge Right |
| S038-SQY-GNYN-NF0 | Conductive Nylon Stainless Steel filled Nylon, suitable for most solvents and alcohols. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Nitrile Max-Pass®Max-Pass® valve made from Nitrile rubber. | NylonA non-metallic material, suitable for most solvents and oils. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | NPT (BSP)NPT(BSP) Connection | Suction Bottom/Discharge RightSuction Bottom/Discharge Right |
| S038-SQY-TVYV-NF0 | Conductive Nylon Stainless Steel filled Nylon, suitable for most solvents and alcohols. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | Viton® Max-Pass®Max-Pass® valve made from Viton® rubber. | NylonA non-metallic material, suitable for most solvents and oils. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Bottom/Discharge Right |
3/8” S038 Solids Handling
Up to 9 GPM
Elastomer Available in: Geolast®, Santoprene®, PTFE
Liquid Connections Available in: FNPT, FBSPT
Max Solids: 1/8 Inch (3.2mm)
Max Suction Lift (Dry): 17ft-H20 (5.2m)
Max Suction Lift (Wet): 30ft-H20 (9.1m)
Air Inlet: ¼ Inch FNPT
3/8” S038 Solids Handling
| Part No. | Fluid End | Air End | Diaphragms | Valve/Ball | Valve Seats | O-Rings | Connection Type | Fluid Porting |
|---|---|---|---|---|---|---|---|---|
| S038-SQK-SEKE-S70 | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | EPDM Max-Pass®Max-Pass® valve made from EPDM rubber. | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Right (NPT/BSP Only)Suction Right/Discharge Right (NPT/BSP Only) |
| S038-SQK-TVKV-S70 | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | Viton® Max-Pass®Max-Pass® valve made from Viton® rubber. | PVDFPolyvinylidene Fluoride suitable in applications requiring the highest purity, strength, and resistance to solvents, acids, bases. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Right (NPT/BSP Only)Suction Right/Discharge Right (NPT/BSP Only) |
| S038-SQP-GNPN-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Nitrile Max-Pass®Max-Pass® valve made from Nitrile rubber. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Right (NPT/BSP Only)Suction Right/Discharge Right (NPT/BSP Only) |
| S038-SQP-SEPE-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Santoprene®Injection molded thermoplastic material with characteristics similar to EPDM. Has excellent abrasion resistance. | EPDM Max-Pass®Max-Pass® valve made from EPDM rubber. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | EPDMGeneral purpose elastomer with good resistance to many acids and basis. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Right (NPT/BSP Only)Suction Right/Discharge Right (NPT/BSP Only) |
| S038-SQP-TVPV-S70 | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | Viton® Max-Pass®Max-Pass® valve made from Viton® rubber. | PolypropyleneA non-metallic material, suitable for water, caustics, soap solutions, mild acids and general purpose applications. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Right (NPT/BSP Only)Suction Right/Discharge Right (NPT/BSP Only) |
| S038-SQY-GNYN-SF0 | Conductive Nylon Stainless Steel filled Nylon, suitable for most solvents and alcohols. | Polypropylene (Glass filled)Polypropylene (Glass filled) | Geolast®Injection molded thermoplastic material with characteristics similar to Nitrile. Has excellent abrasion resistance. | Nitrile Max-Pass®Max-Pass® valve made from Nitrile rubber. | NylonA non-metallic material, suitable for most solvents and oils. | NitrileGeneral purpose elastomer used on water and most non synthetic oils. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Left (NPT/BSP Only)Suction Right/Discharge Left (NPT/BSP Only) |
| S038-SQY-TVYV-SF0 | Conductive Nylon Stainless Steel filled Nylon, suitable for most solvents and alcohols. | Polypropylene (Glass filled)Polypropylene (Glass filled) | PTFEThermoplastic material that is inert to most chemicals. | Viton® Max-Pass®Max-Pass® valve made from Viton® rubber. | NylonA non-metallic material, suitable for most solvents and oils. | Viton®Elastomer with good chemical resistance to a wide variety of chemicals. | NPT (BSP)NPT(BSP) Connection | Suction Right/Discharge Right (NPT/BSP Only) |
